Anionic PHPA Powder for Drill Cuttings Encapsulation and Integrity

Brand Name: Bluwat
Model Number: EC8050 / EA5620
MOQ: 1 Ton
Price: negotiable
Delivery Time: 7-10 Working days
Payment Terms: L/C, D/A, D/P, T/T
Detail Information
Place of Origin:
China
Certification:
ISO
Molecular Weight:
Very High
Charge Degree:
High
Appearance:
Milky White
Solid Content:
38-40%
Bulk Density:
About 1.0
Specific Gravity At 25°C:
1.01-1.05
Shelf Life:
6 Months
Packaging:
1000 Kg IBC Drum
Packaging Details:
1000 kg IBC drum
Product Description
BLUFLOC Powder PHPA

Anionic PHPA Powder for Drill Cuttings Control

Very-high and ultra-high-molecular-weight powder PHPA candidates for cuttings integrity, dispersion control, solids-management screening, and water-based drilling-fluid evaluation.

Four Powder Grades
89% Minimum Solids
0.1-0.3% Solution
25 kg Lined Bags
01

Product Introduction



Intact cuttings are easier to identify and remove than dispersed clay fines, but strong bridging can also alter shaker and centrifuge behavior.

BLUFLOC powder PHPA is described in the supplied family TDS as a water-soluble copolymer of anionic character used in drilling-fluid and selected oilfield applications. The four powder grades span very-high and ultra-high molecular-weight classes with medium or high charge. The table does not assign a unique application to any grade, so the target duty, water, formation, mixing system, and representative test results must decide selection.

02

Application Challenges


Intact cuttings are easier to identify and remove than dispersed clay fines, but strong bridging can also alter shaker and centrifuge behavior.
Reactive shale that disperses into colloidal fines after water exposure
Cavings or hole enlargement with both chemical and mechanical causes
Cuttings that become sticky, soft, or difficult to remove at surface
03

How PHPA Powder Works



PHPA adsorbs at multiple points on shale and drilled solids. A hydrated polymer film can retard dispersion and disintegration, while long chains can encapsulate cuttings and alter solids behavior. In KCl-PHPA muds, KCl and PHPA have complementary roles; chemical inhibition does not replace mud-weight, hydraulics, or geomechanical design.

Molecular-weight and charge classes describe broad polymer behavior, not a guaranteed field result. Powder dispersion, complete hydration, solution concentration, water quality, pH, solids, shear, aging, temperature, and companion chemistry can materially change observed performance.

Important Selection Note

The grades below are screening candidates, not a fixed prescription. Final grade, solution concentration, process dose, preparation, addition point, and acceptance criteria require current grade documentation and representative laboratory and field or plant trials.

04

Recommended BLUFLOC Grade Screening


Grade MW Class Charge Screening Position
HA6518 Very High Medium Screening candidate; selection requires representative testing
HA8520 Very High High Screening candidate; selection requires representative testing
HAA6520 Ultra High Medium Screening candidate; selection requires representative testing
HAA7525 Ultra High High Screening candidate; selection requires representative testing
05

TDS Specifications


Powder Grade Molecular Weight Class Charge Class
HA6518 Very High Medium
HA8520 Very High High
HAA6520 Ultra High Medium
HAA7525 Ultra High High
Family TDS Item Powder Product Value / Guidance
Product form Powder
Appearance White powder
Solid content 89% min
Bulk density About 0.8
Specific gravity at 25°C 1.01-1.10
Shelf life 2 years
Packaging 25 kg kraft paper bags with inner PE liners, palletized
Recommended solution concentration 0.1-0.3% solids
Recommended make-up water temperature 10-40°C
Effective pH range 5-14
TDS mixing guidance About 1 hour; propeller stirrer at 200-500 rpm
TDS confirmation note: Exact active content, viscosity, specification limits, shelf life, and preparation instructions should be confirmed on the current grade-specific TDS and order specification.
06

Powder Preparation and Dosing Guidance



The supplied family TDS recommends preparing powder PHPA at 0.1-0.3% solids with make-up water at 10-40°C and an effective pH range of 5-14. Efficient dispersion is required; a polymer eductor or commercial dry-powder feeder is suggested. After dispersion into agitated water, continue stirring for about one hour. The TDS notes a propeller-type stirrer at 200-500 rpm and recommends separate stock make-up and solution holding tanks. The prepared anionic solutions are described as stable for up to one week. Aluminum, zinc, copper, and iron should be avoided in the make-up system. Confirm all details against the current grade-specific TDS, SDS, equipment manual, and order specification.

Scale-up warning: Do not scale a laboratory rpm directly to a full tank. Validate impeller, tank geometry, feed distribution, water flow, residence time, shear, and solution quality at the intended production rate.
07

Application Advantages to Evaluate


  • Potential fit for anionic PHPA powder for drill cuttings after representative qualification
  • Four TDS-listed molecular-weight and charge class combinations for comparative screening
  • Powder format with at least 89% solids stated in the family TDS
  • PHPA-family compatibility statement covering biopolymers, PAC, and CMC, subject to formulation testing
  • Palletized 25 kg lined bag format for storage, export, and controlled field make-down
08

Recommended Evaluation and Dosing Workflow


  1. Characterize the formation, make-up water, active mud, cuttings, and baseline hole condition.
  2. Prepare each candidate PHPA solution using controlled powder dispersion, hydration time, and concentration.
  3. Build a dose-response screen using shale recovery, dispersion, cuttings integrity, rheology, and fluid loss.
  4. Repeat the preferred condition with the actual KCl, PAC, CMC, biopolymer, solids, and contaminants.
  5. Run a controlled field interval and trend cavings, dilution, solids loading, torque, drag, and mud properties.
09

Product Selection and Compatibility



Treatment Window

Select the lowest treatment window that preserves cuttings long enough for transport and surface removal without excessive agglomeration.

Total Operating Outcome

Compare candidates on polymer solids and achieved operating outcome. Price per bag can be misleading when hydration, make-down losses, dose, equipment throughput, drilling response, fluid recovery, waste, logistics, and downstream costs differ.

10

Operating Indicators to Record


Cuttings size and firmness
Shaker throughput
Screen blinding
Centrifuge feed and discharge
Active-system solids
!
Troubleshooting Note

If performance drifts: When cuttings look better but active solids rise, audit solids-control efficiency and polymer placement rather than assuming underdosing.

11

Packaging, Storage, and Safe Handling



The supplied TDS states that powder products are packed in 25 kg kraft paper bags with inner PE liners and are palletized. Store unopened material in its original packaging in a cool, dry place away from heat, flame, and direct sunlight. The family table states a two-year shelf life for powder products. Protect opened bags from moisture and contamination. Follow the current SDS for personal protection, dust control, spill cleanup, transport, and disposal. Wet polymer is extremely slippery; contain and clean spills promptly.

12

Why Choose Bluwat Chemicals


  • More than 25 years of water-treatment chemical manufacturing experience since 2000.
  • Three production bases supporting factory-direct supply, batch planning, and export coordination.
  • Export experience serving customers in more than 80 countries and regions.
  • Technical screening support using the customer's formation, drilling fluid, brine, produced water, or make-up water.
  • TDS, SDS, COA format, packing details, and available company-level certification documents for commercial review.

For anionic PHPA powder for drill cuttings, Bluwat can review the target duty, water and formation data, make-down equipment, proposed test methods, and the four TDS-listed powder classes with the customer. Company-level certifications or management-system documents should not be represented as grade-specific application approvals unless the applicable certificate explicitly says so.

13

Quality Control and Technical Support


  • Confirm the named grade, current specification limits, order requirements, and documentation before production.
  • Compare candidate grades under the same water chemistry, solids, temperature, shear, mixing, and aging conditions.
  • Record raw-material lot, solution concentration, hydration time, mixing energy, and test method for traceable evaluation.
  • Scale up only after laboratory acceptance criteria and a controlled field or plant trial have been agreed.
14

Frequently Asked Questions


Can PHPA flocculate drilled solids?
Yes. The TDS lists flocculation and bridging, but selectivity must be demonstrated in the actual low-solids system.
Will encapsulated cuttings remain intact indefinitely?
No. Exposure time, shear, temperature, salinity, and mineralogy affect integrity.
Can PHPA solve every shale-instability problem?
No. It can support dispersion control and encapsulation, but pressure imbalance, stress, fractures, trajectory, and unsuitable mud weight require separate diagnosis.
Does PHPA replace KCl in a KCl-polymer mud?
Not automatically. Industry descriptions treat KCl and PHPA as complementary components in many shale-control mud designs.
Request a Representative PHPA Screening Plan

Share the target formation, make-up water, active-fluid chemistry, temperature, solids-control system, and acceptance indicators so the TDS-listed powder grades can be compared under representative conditions.
